TSF2021 Pump General Pump Bare Pump

Description

General Pump TSF 2021 Bare Pump



Features include:

  • Oversized roller bearings
  • Fully anodized crankcase
  • Innovative new seal design extends seal life
  • New plunger design improves thermal shock resistance
  • New valve cap improves hydrostatic performance



Specifications:

  • Horsepower: 21 EBHP
  • Maximum Volume: 8.5 GPM
  • Maximum Discharge Pressure: 3600 PSI
  • Maximum Pump Speed: 1450 RPM
  • Maximum Inlet Pressure: 125 PSI
  • Maximum Inlet Vacuum: 9 ft. water (7.9 in. Hg)
  • Plunger Bore: .787 in. / 20 mm
  • Plunger Stroke: .826 in. / 21 mm
  • Crankcase Oil Capacity: 40.6 oz.
  • Maximum Fluid Temperature: 165 F
  • Inlet Port Thread: 3/4”-14 BSP-F
  • Discharge Port Thread: 3/8”-19 BSP-F
  • Shaft Diameter: .945 in. / 24 mm
  • Weight: 40.7 lbs.
  • Dimensions: 14.94” x 9.78” x 6.99”
Product form

General Pump TSF 2021 Bare Pump   Features include: Oversized roller bearings Fully anodized crankcase Innovative new seal design extends... Read more

$964.00
